500KG Computerized Spring Compression Testing Machine / Tensile Strength Testing Equipment

Name: 500KG Computerized Spring Compression Testing Machine Tensile Strength Testing Equipment
Brand: SKYLINE
Price: 1 USD

Buy cheap 500KG Computerized Spring Compression Testing Machine / Tensile Strength Testing Equipment product

Brand Name : SKYLINE

Model Number : SL-T810

Certification : Calibration Certificate

Place of Origin : China

MOQ : 1 unit

Price : Neogitable

Payment Terms : Western Union, T/T, MoneyGram

Supply Ability : 10 pcs/ month

Delivery Time : 7 working days

Packaging Details : plywood case

SKYLNE : Compression Test Machine

Test Stroke 1000mm : 1000mm

Capacity choice : 100，200，500，1000，2000，5000kg

Test speed 0.05mm~500mm/min : 0.05mm~500mm/min

Test Width Compression plate : 600mm

Dimension : 1200*530*1800mm

Contact Now

500KG Computerized Spring Compression Testing Machine / Tensile Strength Testing Equipment

Product Information:

PC controlled Tensile Strength testing machine is used to test tension, compression, shearing force, adhesion, peeling force, tear strength, etc of specimen, semi-finished and finished products in the field of rubber, plastic, metal, nylon, fabric, paper, aviation, packing, architecture, petrol chemistry, electric appliance, automobile, etc, which are the basic facilities for Input Quality Control, Quality control, physical Inspection, Mechanics Research and Material Development.

Technical:

1.Motor sevro motor

Plate size	600mm
Capacity	200kg
Speed range	0.001~1000mm/min
Resolution	1/500,000
Test speed	0.05mm~500mm/min
Test Stroke	1000mm
Test Width Compression plate	600mm
Test unit	KN,N,tonf(SI),kgf,gf,tonf(long),tonf(short),lbf,ozf,cN
Distance measurement	0.0001mm
Accuracy	±0.1%
Collect rate	0.1~2000Hz
Software language	Chinese,English
Test space	1900 mm(W)×1900 mm(D)×1000 mm(H)
Weight	550 kg
Power	AC-220V,50~60HZ 4A
