SL-7602L Flammability Testing Equipment , Halogen Release Measurement Device

Name: SL7602L Flammability Testing Equipment Halogen Release Measurement Device
Brand: SKYLINE
Price: 1 USD

Buy cheap SL-7602L Flammability Testing Equipment , Halogen Release Measurement Device product

Brand Name : SKYLINE

Model Number : SL-7602L

Certification : CE

Place of Origin : China

MOQ : 1 unit

Price : negotiated

Payment Terms : T/T, L/C, Western Union, MoneyGram

Supply Ability : 1 unit/ month

Delivery Time : 10 work days

Packaging Details : plywood case

Standards : GB/T17650.1-1998, GB/T17650.2-1998, IEC60754-1:1994 etc

Tubular furnace input power : 220V/3.8KW

Inner diameter of quartz tube : ф34±1mm

SKYLINE : Halogen Release Measurement Device

Brand : SKYLINE

Quartz material tubular furnace heating furnace chamber size : L600mm×ф42mm

Contact Now

Halogen Release Measurement Device

Application

Applies to determine total quantity of halogen-free and low halogen flame retardant cable’s halogen acid gas and measure PH value and conductivity to determine the acidity gas.

Main parameter

Quartz material tubular furnace heating furnace chamber size	L600mm×ф42mm
Tubular furnace input power	220V/3.8KW
Inner diameter of quartz tube	ф34±1mm
According to inner diameter of quartz tube gas flow-meter calculate the setting flux	ρ=V·πD2/4=203.14342 /4ml/h=302ml/min±10%
Accessories	pH meter and conductivity analyzer one for each, 500mL gas washing and absorbing device and connection head.

Standard

According to GB/T17650.1-1998, GB/T17650.2-1998, IEC60754-1:1994, IEC60754-2:1991, GB/T19666-2005, GA306.1-2007, GA306.2-2007, UL2556-2007.

SL-7602L Flammability Testing Equipment , Halogen Release Measurement Device

Product Tags:

horizontal flammability tester

flammability test chamber

SL-7602L Flammability Testing Equipment , Halogen Release Measurement Device Images
