Environmental Test Chamber Pressure Control Immersion Test Device Automatic Regulation

Name: Environmental Test Chamber Pressure Control Immersion Test Device Automatic Regulation
Brand: SKYLINE
Price: 1 USD

Buy cheap Environmental Test Chamber Pressure Control Immersion Test Device Automatic Regulation product

Brand Name : SKYLINE

Model Number : SL-IPX8-30A-20L

Certification : CE

Place of Origin : CN

MOQ : 1 unit

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 10 pcs/ month

Delivery Time : 10 working days

Packaging Details : Plywood case

Stainless steel : coated printed

View windown : glass two view windows with lights

Tray : 2 pcs stainless steel trays

Temperature : RT-250C

Temperature display : Digital Temperature display

Standard : SL-IPX8-30A-20L

Contact Now

IPX8 Pressure Control Immersion Test Device Automatic Regulation

The main purpose of environmental test chamber

Under the device with shell protection grade (IP code) based mainly for electronic and electrical products,outdoor lighting,electric cabinet,communication equipment,diving equipment and other products to simulate the water environment to test the protective performance of IP products. The test results are used to determine whether the requipment are met,so as to provide the design,development,optimization and ex factory inspection of the product.

Model	SL-IPX8-30A-20L	SL-IPX8-50A-100L
Inner dimension	Inner diameter×height	Inner diameter×height
Outer dimension	460×580×900mm	600×780×1300mm
Flange thickness	20mm	25mm
Wall thickness	3mm	4mm
Range of test depth	0-30m	0-50m
Range of test pressure	0-0.3Mpa / 0-3bar	0-0.5Mpa / 0-5bar
Pressure display mode	Pressure pickup
Pressure control mode	Automatic regulation
Power	100w
Supply voltage	220v

Testing principle

The air pressure is applied to make the compressed air generate pressure on the water body,so

as to simulate the corresponding water depth environment.
